When the setting to create XREFs during IFC IMPORT is active, you can not open an IFC file with drag and drop, and you should use IMPORT.
In some cases, invalid NOTDEFINED values will be ignored.
IFCIMPORT: IFCIMPORT is more forgiving towards invalid IFC files.
HIGHLIGHT: Fixed regression: a solid is not highlighted in SOLIDEDIT/BODY/SHELL if SELECTIONPREVIEW is ON.
Such drawings now open successfully, but display an error at the command line.
Field: Certain invalid fields could crash and prevent drawings from opening.
Dimensions: Fixed: Dimensions between centermarks/centerlines do not keep the annotative property.
DRAWING EXPLORER: Fixed regression: layer preview inside the Drawing Explorer no longer displays the entities of the selected layer.
Color Dialog Box: The missing RGB value display in the Index Color panel of the Select Color dialog has been restored.
CRS with inverted axesWMS requests for CRS with inverted axes (x - northing, y - easting) were fixed.
COM: The property has been implemented.
#Window hand pane in bricscad for mac code
BLADE: Fixed a defect in Beautify/Reformat function, when a line comment contains an unbalanced number of ( and ) braces :subsequent code lines got a wrong indentation.
BEDIT: Fixed an endless loop (stack overflow crash) when ANNOAUTOSCALE > 0, and no dimension block is present for "1:1" annotation scale.
BATTMAN: Fixed a crash when the BATTMAN command is executed for drawings with non attributed BLOCKS with the "hasAttributes" flag set to ON.
Application: Fixed a crash after choosing No when prompted to open a read only drawing file by SHELL command.
ATTSYNC: Fixed a V22.2 regression that caused attributes to move incorrectly during the ATTSYNC command.
AECC: Civil 3D labels using background mask are now displayed correctly.
The files could not be opened (regression in V19-V22).
2D Constraints: Fixed a compatibility issue with.
-LAYER: It is now possible to enter or choose the localized name for "Default" lineweight when specifying a layer lineweight in local language installations.
SMCONVERT: Recognition of form features was improved.
Singleton: Specifying both a user profile and a drawing file at the command line caused the specified user profile to be ignored when deciding whether to open the specified drawing file in an already running application instance.
Parameters Manager panel: Improved display of Name, Expression, Description cells.
